SLK 6525(MB-J09) Metal Bellows Seal
| Type ： |
SLK 6525 |
| Temperature： |
-29℃～+204℃ |
| Technical parameters： |
Yes |
| Pressure force： |
≤2.1MPa |
| Line rate： |
≤25m/s |
| Materials： |
Rotary Ring (SiC/TC) Stationary Ring (SiC/Carbon/TC) Secondary Seal (VITON/Encapsulated Ring/PTFE) |
Order Hotline：0086-512-58728158
SLK 6525 Metal Bellows Seal(replace John crane 6525 )
Operating Limits:
Pressure: ≤2.1MPa
Speed: ≤25m/s
Temperature: -29℃~+204℃
Rotary Ring (SiC/TC)
Stationary Ring (SiC/Carbon/TC)
Secondary Seal (VITON/Encapsulated Ring/PTFE)
Metal Bellows (SUS316L/AM350/Inconel718/Titanium/Hastelloy-C/AIIoy-20)
Other Parts (SUS304/SUS316/Titanium/Hastelloy-C)
