SLK MFL85N Metal Bellows Seal
| Type ： |
SLK MFL85N |
| Temperature： |
-40℃～+220℃ |
| Technical parameters： |
Yes |
| Pressure force： |
≤2.5MPa |
| Line rate： |
≤20m/s |
| Materials： |
Rotary Ring(SiC /Carbon/TC) Stationary Ring (SiC /TC) Secondary Seal (VITON/Encapsulated Ring/PTFE) |
Order Hotline：0086-512-58728158
SLK MFL85N Metal Bellows Seal(replace BURGMAN MFL85N(F) )
Operating Limits :
Pressure1≤2.5MPa
Speed:≤20m/s
Temperature1-40℃~+220℃
Rotary Ring(SiC /Carbon/TC)
Stationary Ring (SiC /TC)
Secondary Seal (VITON/Encapsulated Ring/PTFE)
Metal Bellows (SUS316L/AM350/Inconel718/Tltanlum/Hastelloy-C/Alloy-20)
Other Parts (SUS304/SUS316/Tltanium/Hastelloy-C)
